Material Electrical Mechanical Enviromental
  • Shell: Aluminum Alloy
  • Insulator: High-performance thermoplastic
  • Contacts: Copper Alloy
  • Seal: Fluorosilicone
  • Rated Current :3A Maximum Per Pin
  •  Insulation Resistance : 500V DC, >5000MΩ
  • Vibration: 20g
  • Shock: 50g, 3 axes
  • Durability: 500 Cycles
  • Salt Spray: 48H/96H/500H/1000 Options
  • Operation Temperature: -55° C to +175° C
  • Water Immersion: IP68 mated condition
