Material Electrical Mechanical Enviromental
  • Shell: Aluminum Alloy
  • Insulator:Aluminum Alloy
  • Contacts: Copper Alloy
  • Seal: Fluorosilicone
  • Rated Current : 5A Max.
  • Insulation Resistance : 100V DC, >100MΩ min
  • Data Rated :  USB3.0 GEN1, 5 Gbit/s
  • Vibration: 10g, 3 axes
  • Shock: 50g, 3 axes
  • Durability: 500 Cycles
  • Salt Spray: 48H/96H/500H/1000 Options
  • Thermal Shock: -40° C to +85° C
  • Water Immersion: IP68 mated condition
