Material Electrical Mechanical Enviromental
  • *Cage: Copper Alloy with Nickel Plated.
  • *Housing: High Temperature Thermoplastic Glass Filled, UL94 V-0, Black
  • *Kick-out Spring: Copper Alloy with Nickel Plated.
  • *Contact: Copper Alloy with Au Plated.
  • *Light Pipe: PC, Clear.
  • *EMI Springs: Stainless
  • *Contact Resistance: 70 mΩ Max.
  • *Insulation Resistance: 1000 mΩ Min.
  • *Withstanding Voltage: 300V AC.
  • *Transceiver Insertion Force: 40N Max.
  • *Transceiver Extraction Force: 11.5N Max.
  • *Durability: 100 Cycles.
Thermoplastic DUST COVER Silicone DUST COVER
V V
